Universal Marine Diesel M-50B Specifications, serviced by trained technicians at Santa Barbara Marine Diesel Mechanic. servicing Ventura, Oxnard, Channel Islands Harbor & Santa Barbara. UNIVERSAL MARINE MECHANIC
Here are the detailed specifications for the Universal Marine Diesel M-50B engine, as typically serviced by 805 Marine Mechanics in Ventura, Channel Islands, and Santa Barbara. For precise and detailed information, it’s always best to contact 805 Marine Mechanics directly.
Universal Marine Diesel M-50B Specifications
- Engine Model: Universal M-50B
- Configuration: 4-cylinder, 4-stroke diesel engine
- Displacement: 2.2 liters (2200 cc)
- Bore and Stroke: 87 mm x 92 mm (3.43 in x 3.62 in)
- Aspiration: Naturally aspirated
- Power Output:
- 45 horsepower (33.6 kW) at 2800 RPM
- Maximum Torque: Data not typically specified; varies with load and RPM
- Fuel System: Indirect injection
- Cooling System: Freshwater cooled with heat exchanger
- Lubrication System: Wet sump
- Dry Weight: Approximately 234 kg (515 lbs)
- Dimensions:
- Length: 831 mm (32.7 in)
- Width: 610 mm (24 in)
- Height: 606 mm (23.9 in)
- Emission Compliance: Typically complies with marine emission standards at the time of manufacture
- Starting System: 12V electric start
- Oil Capacity: 6.6 liters (7 quarts)
- Fuel Consumption: Approximately 3.2 liters per hour (0.85 gallons per hour) at cruising speed
Key Features:
- Robust and Reliable Design: Ideal for a variety of marine applications, including medium to larger sailboats and powerboats.
- High Performance: Delivers reliable power and fuel efficiency.
- Ease of Maintenance: Designed with accessible service points for easy maintenance and servicing.
- Freshwater Cooling: Maintains consistent operating temperatures and prolongs engine life.
Applications:
- Suitable for medium to larger sailboats, powerboats, and other marine vessels requiring dependable auxiliary power.
Additional Information:
- Durability: Known for its robust construction and long service life, making it a popular choice among marine operators.
- Service and Support: Supported by a wide network of parts and service providers.
Contact 805 Marine Mechanics:
For detailed information, personalized advice, or to schedule maintenance and service, contact 805 Marine Mechanics servicing Ventura, Channel Islands, and Santa Barbara:
Services Offered by 805 Marine Mechanics:
- Engine Installation: Professional installation services for Universal M-50B engines.
- Maintenance and Repairs: Comprehensive maintenance and repair services to ensure optimal engine performance.
- Custom Modifications: Tailored solutions to meet specific needs and enhance engine performance.
- Technical Support: Expert technical support and troubleshooting assistance.
For the most accurate and specific details, please refer to the official documentation provided by Universal or directly consult with 805 Marine Mechanics.
SERIAL NUMBER LOCATION
An identification nameplate that displays the engine model
number and engine serial number is mounted on the side of
the engine’s manifold. Take the time to enter this information.
on the blank decal provided below. This will provide a quick
reference when seeking technical information and/or ordering.
parts.
UNDERSTANDING THE DIESEL ENGINE
The diesel engine closely resembles the gasoline engine, since the mechanism is essentially the same. The cylinders are arranged above a closed crankcase; the crankshaft is of the same general type as that of a gasoline engine, and the diesel engine has the same types of valves, camshaft, pistons, connecting rods and lubricating system. To a great extent, a diesel engine requires the same preventive maintenance as a gasoline engine. Most important are. proper ventilation and proper maintenance of the fuel, lubricating and cooling systems. Replacement of fuel and lubricating filter elements at the time periods specified and
frequent checking for contamination (water, sediment, etc.) in the fuel system are essential. Also important is the consistent use of a brand of high detergent diesel lubrication oil
designed specifically for diesel engines. The diesel engine does differ from the gasoline engine, however, in its method of handling and firing of fuel. The carburetor and ignition systems are done away with and in their place is a single component (the fuel injection pump) which. performs the function of both. Universal Marine Diesel M-50B Specifications.
